Techtop

BMS0014C-TC

1.5HP, 1800RPM, 115/208-230V, 1PH, 143TC, Rigid/C-Flange, TEFC

Catalog Number: BMS0014C-TC

Specifications

Motor type Brake Motors Single Phase

HP 1.5

RPM 1800

Phase 1

Frame 143TC

Mounting Rigid/C-Flange

Enclosure TEFC

Material Cast Aluminum

Request a quote

Any questions or ready to order?

Technical assistance & free estimate

Electrical Data
Rated Motor Output Power	1.5 HP
Rated Motor Speed	1745 tr/min
Rated Motor Voltage (+/-10%)	115/208-230 V
Rated Motor Current	13.0/7.21-6.52 A
Phase	1
Poles	4
Locked Rotor Current @ High Voltage	42.06
Current Fl @ 208V	7.21
Service factor	1.15
KVA code	H
Nominal efficiency	82
Rated power factor	0.9
Cables (Qty, Size)	6 \|
Frequency	60 Hz
Connection	70μF/250V
Start capacitor	400μF/165V
Run capacitor	-
VFD DUTY (S.F. 1.0)	RATIO
Variable Torque
Constant Torque
SITE CONDITIONS
Ambient Temperature (℃)	40ºC
Meters Above Sea Level (MASL)	1000

General Data
Frame Size	145TC
Enclosure	TEFC
Mounting	Rigid/C-Flange
Number of speeds	-
Approximate weight	53 lbs.
Casing Material / Fan Cover	Cast Aluminum	\|	Steel
Shaft Material	1045
NEMA design	L
Degree of protection (IP)	55
Insulation class	F	\|	B
Rotation	Réversible
Service	Continu
Conduit Box Location	F1
Feet Removable / Double Drilled	Yes	\|	Yes
Paintwork	7024	\|	Graphite Gray
Mechanical Data
Bearing DE Side	6205 ZZ
Bearing ODE Side	6205 ZZ
Grease Type	ASE-L
Compensation Ring (wavy washer)	NDE
Moment of Inertia (lb-ft2)	-
Sound Pressure @ 3 FT dBA	60

Features

Removable feet F1, F2, F0 field convertible
1.25 Service Factor through 3/4HP, 1.15 Service Factor 1HP and larger
18 Month warranty
Cast aluminum construction with cast aluminum c-flanges
Anti-microbial (tropicalization) on stator winding
Compact lightweight design
Dual oversized shielded bearings
1045 Steel shaft
Surface finish:
- Powder coated RAL7024 - Graphite Gray
Stainless steel nameplate
Corrosion resistant hardware
Normally closed electromagnetic spring-loaded Fail-Safe DC brake
Bridge rectifier used for AC to DC conversion, located inside motor terminal box
Manual brake release included
Solid-state electronic switch, located inside motor terminal box
Alternate brake voltages and rectifiers available

Operating parameters

Continuous (S1) duty
Ambient temperatures up to 40ºC
Installation up to 1000 MASL (3300 ft.)

Ingress protection

The standard degree of motor enclosure protection is IP55. Brake components are rated IP54. Both drive end and non-drive end end bells are fitted with double lip oil seals, including a rubber shaft slinger on the drive end. Terminal box is double gasketed. DE/NDE end bell fitted with sintered brass one-way drain. Brakes come with an anti-dust wrapper installed.
