Techtop
DC40N
0.33HP, 1800RPM, 90V, 1PH, 56C, Rigid/C-Flange, TENV- Catalog Number: DC40N
Specifications
Motor type
Permanent Magnet DC Motors
HP
0.33
RPM
1800
Voltage
90
Phase
1
Frame
56C
Mounting
Rigid/C-Flange
Enclosure
TENV
Material
Rolled Steel
| Electrical Data | |
|---|---|
| Rated Motor Output Power | 0.33 HP |
| Rated Motor Speed | 1750 tr/min |
| Rated Motor Voltage (+/-10%) | 90 V |
| Rated Motor Current | 3.6 A |
| Phase | 1 |
| Poles | 6 |
| Locked Rotor Current @ High Voltage | - |
| Current Fl @ 208V | - |
| Service factor | 1.15 |
| KVA code | - |
| Nominal efficiency | - |
| Rated power factor | - |
| Cables (Qty, Size) | 2 |
| Frequency | 60 Hz |
| Connection | - |
| Start capacitor | - |
| Run capacitor | - |
| VFD DUTY (S.F. 1.0) | RATIO |
| Variable Torque | - |
| Constant Torque | - |
| SITE CONDITIONS | |
| Ambient Temperature (℃) | 40ºC |
| Meters Above Sea Level (MASL) | 1000 |
| General Data | |||
|---|---|---|---|
| Frame Size | 56C | ||
| Enclosure | TENV | ||
| Mounting | Rigid/C-Flange | ||
| Number of speeds | - | ||
| Approximate weight | 23 lbs. | ||
| Casing Material / Fan Cover | Rolled Steel | | | Steel |
| Shaft Material | 1045 | ||
| NEMA design | - | ||
| Degree of protection (IP) | 44 | ||
| Insulation class | F | | | - |
| Rotation | No | ||
| Service | Continu | ||
| Conduit Box Location | F0 | ||
| Feet Removable / Double Drilled | Yes | | | - |
| Paintwork | - | | | - |
| Mechanical Data | |||
| Bearing DE Side | - | ||
| Bearing ODE Side | - | ||
| Grease Type | - | ||
| Compensation Ring (wavy washer) | - | ||
| Moment of Inertia (lb-ft2) | - | ||
| Sound Pressure @ 3 FT dBA | - | ||
Features
- SCR Rated
- 20:1 Constant Torque speed range
- 1.15 Service Factor
- 12 Month warranty
- Cold rolled steel construction with NEMA c-flanges and removable bases
- Double shielded permanently lubricated ball bearings
- 1045 Steel shaft
- Surface finish:
- Alkyd enamel RAL7024 - Graphite Gray
- Corrosion resistant hardware
- Replacement parts available
Operating parameters
- Continuous (S1) duty
- Ambient temperatures up to 40ºC
- Installation up to 1000 MASL (3300 ft.)
Ingress protection
The standard degree of enclosure protection is IP44 (Weather Proof). Conduit box lid and body are sealed with fitted foam gaskets.
Insulation and inverter rating
- 20:1 Constant Torque speed range
- Class F Insulation
- Designed to Class B temperature rise
